L05C street light function lighting L05C-B traveler fixture
  • L05C street light function lighting L05C-B traveler fixture
  • L05C street light function lighting L05C-B traveler fixture

L05C street light function lighting L05C-B traveler fixture

Company:

Zhejiang Ouruijie Lighting Technology Co., Ltd.

Tel:

+86-158 6823 3820

E-mail：

quentin@ruirock.com
Contact Us
PREV：L05C street light function lighting L05C-A traveler fixture
NEXT：L05C street light function lighting L05C-C traveler fixture

L05C street light function lighting L05C-B traveler fixture

L05C street light functionlighting L05C-B traveler fixture is a smart system communication protocol Zigbee ; LoRa ; NB-IOT; 5GLED DriverMEANWELL or SOSEN . (Philips，OSRAM or INVENTRONICS as reuest)Electrical ClassClass I as standard，Class II as requestOperating Temperature Range-40°C~+55CSurge Protection10KV ; 20KV as requestIP RatingIP 66IK RatingIK 10CertificationCE CB IP66 IK10 Lm79 test by DEKRA Lab (Rohs i pccess).L05C-B street light fixture which is based on IOT technology, it uses seven LED light sources, which has the same brightness and color rendering index as a 35W traditional bulb. It can be used in the residential area, tourism camp and commercial buildings.

PRODUCT PARAMETER

ACCESSORIES

L05C-B
LED Qty 36 24 12
Current [mA] 375 375 375
Power 90 60 30
Lumen 12524 8380 4158
Light Source LUMILEDS 5050 or 3030 as standard (OSRAM or CREE chips opionE;
CRI > 70 as standard , 80 or 90 as request
Luminaire Eficiency 134- 150Lm/W @ Ultra clear Tempered glass
Lumen Maintenance [L70] ≥100,000 hrs
Lumen Maintenance [L90B10] ≥50,000 hrs
Optics Material PC/PMMA (LEDIL, LEDLINK)
Optics Cover 6mm Ultra clear Tempered glass
Hardware Interface for LCU NEMA ; ZHAGA As Request
Antenna solution Build in NEMA or ZHAGA based LCU ; Build in body and beside the glass ; Cuts.de cE body as receust
Smart System Communication Protocol Zigbee ; LoRa ; NB-IOT; 5G
LED Driver MEANWELL or SOSEN as standard . (Philips，OSRAM or INVENTRONICS as reuest)
Electrical Class Class I as standard，Class II as request
Operating Temperature Range -40°C~+55C
Surge Protection 10KV ; 20KV as request
IP Rating IP 66
IK Rating IK 10
Certification CE CB IP66 IK10 Lm79 test by DEKRA Lab (Rohs i pccess)
inquiry
PREV：L05C street light function lighting L05C-C traveler fixture
NEXT：L05C street light function lighting L05C-A traveler fixture

ABOUT ORJ

Zhejiang Ouruijie Lighting Technology Co., Ltd. is an innovative R&D and manufacturing enterprise, the company is China L05C street light function lighting L05C-B traveler fixture suppliers and Custom L05C street light function lighting L05C-B traveler fixture factory.
Ouruyie Lighting Technology Co., Ltd. is a national high-tech enterprise, a member of the China Illuminating Society and Zhejiang Illuminating Society, and participates in the formulation of national and industry standards.
The company is building a smart research and development industrial base with an investment of 150 million, covering an area of 31 acres, a building area of 28,000 square meters, a national standard laboratory of 2000 square meters, covering a series of experimental equipment such as optics, safety regulations, electromagnetic interference, etc., and a scene display center of 2000 square meters, 200 square meters of dust-free SMT automatic patch production line, 10 lamp production and aging lines, and a series of supporting automatic production equipment, with an annual output of 600,000 sets of smart lighting production capacity, is expected to be put into use in 2022.
