New generation, energy saving LED light source fits into L05C-CLED QTY8064, providing high CRI (80 or above), 2800K~5500K and 6700k available, driving Eu standard driver - Meanwell and etc. High efficiency; low heat generation; long lifespan.
L05C-CLED LIGHTING APPLICATION: The lighting products proposed by us are created with high technical requirements and optimized through many instances of testing.L05C-CLED traveler is a high performance light with a high efficiency in traffic and street lighting. It can be applied to the area of highway, road, pavement, tunnel and bridge way that require higher illumination requirements. The L05C-CLED has the power factor of PF>0.9.
PRODUCT PARAMETER
ACCESSORIES
| L05C-C | ||
| LED Qty | 80 | 64 |
| Current [mA] | 338 | 352 |
| Power | 180 | 150 |
| Lumen | 26472 | 21892 |
| Light Source | LUMILEDS 5050 or 3030 as standard (OSRAM or CREE chips opionE; | |
| CRI | > 70 as standard , 80 or 90 as request | |
| Luminaire Eficiency | 134- 150Lm/W @ Ultra clear Tempered glass | |
| Lumen Maintenance [L70] | ≥100,000 hrs | |
| Lumen Maintenance [L90B10] | ≥50,000 hrs | |
| Optics Material | PC/PMMA (LEDIL, LEDLINK) | |
| Optics Cover | 6mm Ultra clear Tempered glass | |
| Hardware Interface for LCU | NEMA ; ZHAGA As Request | |
| Antenna solution | Build in NEMA or ZHAGA based LCU ; Build in body and beside the glass ; Cuts.de cE body as receust | |
| Smart System Communication Protocol | Zigbee ; LoRa ; NB-IOT; 5G | |
| LED Driver | MEANWELL or SOSEN as standard . (Philips，OSRAM or INVENTRONICS as reuest) | |
| Electrical Class | Class I as standard，Class II as request | |
| Operating Temperature Range | -40°C~+55C | |
| Surge Protection | 10KV ; 20KV as request | |
| IP Rating | IP 66 | |
| IK Rating | IK 10 | |
| Certification | CE CB IP66 IK10 Lm79 test by DEKRA Lab (Rohs i pccess) | |
